Outdoor 4 Core Fiber Optic Cable Armored Stranded Gyts 4a Fiber Optics Cables

Negotiable
MOQ
Negotiable
Price
Outdoor 4 Core Fiber Optic Cable Armored Stranded Gyts 4a Fiber Optics Cables
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 4 Core Fibre Optics Cables
Outer Sheath Material: PVC
Outer Sheath Color: Black
Metallic Strengthen Member: Steel Wire
Loose Tube Material: PBT Or Jelly
Operating Temperature: -40 Degree ~ +60 Degree
Installation Methods: Aerial &Duct
Core Count: 4 Core
Type: GYTS
Fiber Count: 4-288
High Light:

Stranded 4 Core Fiber Optic Cable

,

Armored 4 Core Fiber Optic Cable

,

Gyts 4a Fiber Optics Cables

Basic Infomation
Place of Origin: China
Brand Name: Aitong
Certification: ISO9001
Model Number: GYTA
Payment & Shipping Terms
Packaging Details: Wooden drum/ Customized
Delivery Time: 5-8 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 100km/Day
Product Description





Factory direct sales of 4-core outdoor armored stranded fiber optic cable gyts-4a fiber optic cable





Product Description



GYTS optical cable is a communication cable with the same transmission speed as light. GYTS optical

cable has wide bandwidth, fast transmission speed, good confidentiality, anti-electromagnetic interference,

good insulation, long life and good chemical stability. GYTS optical cable is mainly divided into two types:

GYTS multi-mode optical cable and GYTS single-mode optical cable.



Application



Suitable for telecommunications, railways, video surveillance, new energy, cable television
And many other fields



Feature



◆ The material of the loose tube itself has good hydrolysis resistance and high strength
◆ The special ointment is filled in the tube, which provides the key sealing protection for the optical fiber
◆ PE sheath has good anti-ultraviolet radiation performance
◆ A single steel wire center strength core helps to parallel and stretch the cable
◆ Anti-stretching, anti-wear, anti-impact, anti-flattening, can be repeatedly bent, twisted, bent, curved (bending angle not more than 90°) shooting, etc., with good mechanical properties and temperature characteristics
◆ The double-sided corrugated steel tape (PSP) improves the moisture resistance of the optical cable, and the corrugated part can be better combined with PE to make the structure stronger.
◆GYTS single-mode optical cable has the advantages of fast transmission speed and long distance, good confidentiality, anti-electromagnetic field interference, good insulation, good chemical stability, long life and low loss, and has good characteristics and economic benefits.
◆ Suitable for long-distance communication and inter-office communication
◆ Laying method: overhead pipeline tunnel
◆ Applicable temperature range: -40℃—+60℃

Specification

TYPE CORE Loose tube Filling rope

OD

(mm)

WT

Kg/km

Allowable pull(N) Allowable flattening force(N/100mm) Bending radius(mm)
GYTA/2-6 2-6 1 4 9.2 80 600/1500 300/1000 10D/20D
GYTA/8-12 8-12 2 3 9.2 80 600/1500 300/1000 10D/20D
GYTA/14-18 14-18 3 2 9.2 80 600/1500 300/1000 10D/20D
GYTA/20-24 20-24 4 1 9.2 80 600/1500 300/1000 10D/20D
GYTA/26-30 26-30 5 0 9.2 80 600/1500 300/1000 10D/20D
GYTA/32-36 32-36 6 0 9.7 97 1000/3000 300/1000 10D/20D
GYTA/38-48 38-48 4 1 10.5 109 1000/3000 300/1000 10D/20D
GYTA/50-60 50-60 5 0 10.5 109 1000/3000 300/1000 10D/20D
GYTA/62-72 62-72 6 0 11.5 126 1000/3000 300/1000 10D/20D
GYTA/74-84 74-84 7 1 13.2 153 1000/3000 300/1000 10D/20D
GYTA/86-96 86-96 8 0 13.2 153 1000/3000 300/1000 10D/20D
GYTA/98-108 98-108 9 1 14.6 182 1000/3000 300/1000 10D/20D
GYTA/110-120 110-120 10 0 14.6 182 1000/3000 300/1000 10D/20D
GYTA/122-132 122-132 11 1 16.5 221 1000/3000 300/1000 10D/20D
GYTA/134-144 134-144 12 0 16.5 221 1000/3000 300/1000 10D/20D
GYTA/146-216 146-216 18 0 16.5 222 1000/3000 300/1000 10D/20

Outdoor 4 Core Fiber Optic Cable Armored Stranded Gyts 4a Fiber Optics Cables
