Metal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black Sheath

Negotiable
MOQ
Negotiable
Price
Metal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black Sheath
Features Gallery Product Description Request A Quote
Features
Specifications
Application: FTTX,FTTH FTTB FTTX Network,Telecom
Conductor: Optical Fiber
Sheath Color: Black,black/white,White Or As Required
Types: Butterfly Drop,Self-supporting
Scope Of Application: Power Engineering, Optical Fiber To Homes, Lightning Protection
Packing: 1km Or 2km,Customized
Permissible Side Pressure: 660 (N / 100 Mm)
Operating Temperature: -40℃- +70℃
Insulator: Teflon
High Light:

Butterfly FTTH Fiber Optic Cable

,

Introduced FTTH Fiber Optic Cable

,

FTTH drop wire fiber optic 2 core

Basic Infomation
Place of Origin: China
Brand Name: Aitong
Certification: ISO9001/ISO14001/ISO25001
Model Number: GJXFH-2B
Payment & Shipping Terms
Packaging Details: wooden drum
Delivery Time: 5-8days
Payment Terms: L/C, T/T, T/T, Western Union, MoneyGram
Supply Ability: 150000KM/mouth
Product Description

Metal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black Sheath





Product description



GJXFH-2B optical cable is the optical communication unit in the center, two parallel strengthening elements are placed on both sides, and finally squeezed into a layer of sheath.Special flexural cable, providing greater bandwidth, enhance network transmission characteristics;







Application

  • The product is small in size, light in weight, compact in structure, and has a unique groove design, which can be unpacked without tools
  • Indoor drop cable: Small size, especially suitable for adding lines to existing pipelines.
  • As one of the professional fiber optic accessories suppliers, TUOLIMA can customize the optical cable according to your requirements.
  • New environmental protection material resistant to high temperature and corrosion
  • Realize the application under engineering emergency and special conditions.

Characteristics

  1. Two parallel FRP makes the cable have good compressive performance and protect the cable.
  2. The optical cable is simple in structure, light in weight and practical.
  3. Unique groove design, easy to peel, convenient connection, simple installation and maintenance;
  4. Low smoke halogen free flame retardant sheath, environmental protection.

General Specifications:



Cable Type FTTH(Drop Cable)
Fiber Type SM G657A1/ SM G657A2
Application FTTH, LAN
Recommended installation methods Aerial
Environment Indoor
Temperature Range -40℃ to 70℃







Fiber Specifications:



Fiber style Unit SM
G652D
SM
G657A1
SM
G657A2
condition nm 1310/1550 1310/1550 1310/1550
attenuation dB/km ≤0.36/0.23 ≤0.35/0.21 ≤0.35/0.21
Dispersion 1310nm Ps/(nm*km) ≤18 ≤18 ≤18
1550nm Ps/(nm*km) ≤22 ≤22 ≤22
Zero dispersion wavelength nm 1312±10 1312±10 1300-1324
Zero dispersion slope ps/(nm²×Km) ≤0.091 ≤0.090 ≤0.092
PMD Maximum Individual Fiber [ps/√km] ≤0.2 ≤0.2 ≤0.2
PMD Design Link Value ps/(nm²×Km) ≤0.08 ≤0.08 ≤0.08
Fiber cutoff wavelength λc nm ≧1180,≤1330 ≧1180,≤1330 ≧1180,≤1330
Cable cutoff wavelength λcc nm ≤1260 ..... .....
MFD 1310nm um 9.2±0.4 9.0±0.4 9.8±0.4
1550nm um 10.4±0.8 10.1±0.5 9.8±0.5
Step(mean of bidirectional measurement) dB ≤0.05 ≤0.05 ≤0.05
Irregularities over fiber length and point discontinuity dB ≤0.05 ≤0.05 ≤0.05
Difference backscatter coefficient dB/km ≤0.03 ≤0.03 ≤0.03
Attenuation uniformity dB/km ≤0.01 ≤0.01 ≤0.01
Cladding diameter um 125.0±0.1 124.8±0.1 124.8±0.1
Cladding non-circularity % ≤1.0 ≤0.7 ≤0.7
Coating diameter um 242±7 242±7 242±7
Coating/chaffinch concentrically error um ≤12.0 ≤12.0 ≤12.0
Coating non circularity % ≤6.0 ≤6.0 ≤6.0
Core/cladding concentricity error um ≤0.6 ≤0.5 ≤0.5
Curl(radius) um ≥4 ≥4 ≥4





Product mix



Metal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black SheathMetal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black Sheath



Metal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black Sheath





Standard Color Identification of Fiber



No. 1 2 3 4
Color Blue Orange Green Brown



Cable Design



Item Description
Model No GJXH/GJFXH
1. Fiber count 1 Core , 2 Core, 4 Core
2. Cable Diameter 3.0*2.0mm
3. Cable Weight 11.5KGS/9.5KGS
4. Strength member
- Material Steel/FRP
- Diameter 0.45mm
5.Outer Sheath
- Material LSZH (Black/white)
6. Sheath marking
- Type of marking Laser printing





Packing

Metal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black SheathMetal Butterfly FTTH Fiber Optic Cable Indoor GJXFH2B PVC Black Sheath
Items Description
Cable length 1KM or 2KM per reel
Package material drum+carton
Package size 1KM 31.5*21*32.5cm
2KM 34.5*28*35cm





FAQ



Q1: Where is your factory ?
A1: Our factory is located in DONGGUAN City, GUANGDONG Province, China.
Q2: How long has your company been doing this?
A2: More than 20 years.We are not only produce fiber optical cable but also produce optical fiber and related tools .
Q3: How about the cable's quality?
A4: Our factory is approved by ISO9001 quality management system and including STARF,CE,CPR,TLC certifications at list.We have a series of equipment and instruments to make sure reliable quality of our products.
Q4: Can you produce cable as our requirements?
A6: Of course .We can supply different types of products according to your requirements with reasonable prices .
Q5: Do you accept the OEM order and how many is the MOQ?
A7: Yes,we warmly welcome your OEM order.To achieve customer's satisfaction,we accept sample order, even one Piece.
