SC Connector Single-Mode GJYXCH Outdoor 1 Wire Optical Fiber Patch Cord
▌Product Description
Fiber Patch Cord or jumper is a fiber cable that has fiber connectors terminated on one or both ends. General use of these cable assemblies includes the interconnection of fiber cable systems and optics-to-electronic equipment.
As a quality fiber optic patch cord factory, T&S provides types of custom simplex, duplex, single-mode (SM), and multi-mode (MM) fiber patch cords and fiber pigtail assemblies with various types of fiber connectors including ST, FC, SC, LC, MU, MTRJ, E2000 and so on.
Our fiber optic cable patch cord and pigtail range offer choices of any length, connector types, and either PVC or LSZH cable jacket, and all cable assemblies are composed of our top quality ceramic ferrules and fiber connectors housings which ensures stable performance at a high-quality level. Except for standard Fiber Patchcord, we supply other types of Patch cord, including Grade B patch cord, IP68 LC/SC patch cord, LC/SC loopback, outdoor Patchcord, etc. for different applications as well.
▌Features
. Special bending-resistant optical cables provide greater bandwidth and enhance network transmission characteristics;
· 3 steel wires make the optical cable have good compression resistance outdoors and protect the optical cable;
· Optical cable has simple structure, light weight and strong practicability;
· Unique groove design, easy to peel off, convenient to connect, simplify installation and maintenance;
▌Application
● Applicable to special cases that has no room for installation of Cassette type PLC splitter
● FTTX/FTTH Systems
● CATV Links
● Optical Signal Distribution
● Passive Optical Networks (PON)
● DWDM/CWDM systems
● Test equipment
● LAN/MAN/WAN network
▌Parameter
| Connector type | FC, SC,LC,ST,MU, E2000 ,D4, DIN | |||
| Fiber mode | SM | MM | ||
| End face | PC | UPC | APC | PC |
| |IL(dB) | |≤0.3 | s0.2 | S0.3 | ≤0.3 |
| RL(dB) | ≥45 | ≥50 | 260 | ≥35 |
| Other model | MT-RJ,MPO | |||
| |IL(dB) | |s0.7 | ≤0.7 | ≤0.5 | |
| RL(dB) | |≥30 | ≥50 | ≥25 | |
| arameters | Unit | Specification | ||
| Center Wavelength | nm | 1310&1550 | ||
| Max. Insertion Loss | dB | 0.5 dB (Typical) 0.8 dB (Max) | ||
| Return Loss | dB | >55 dB (FC/APC and No Connectors) | ||
| 50 dB (FC/PC) | ||||
| Max.Polarization Dependent Loss | 0.05 | |||
| Polarization Mode Dispersion | ps | 0.05 | ||
| Faraday Rotation Angle (single pass) | degree | 45 | ||
| Rotation Angle Tolerance | 1 | |||
| Fiber Type | SMF-28XB | |||
| Connector Type | FC/SC/LC/ST or NONE | |||
| Maximum Optical Power | No Connectors: <3 W | |||
| FC/PC or FC/APC Connectors: <300 mW | ||||
| Maximum Tensile Load | N | 5 | ||
| Operating Temperature | °C | -5 to +70 | ||
| Storage Temperature | °C | -40 to +85 | ||
| Fiber Length | m | 1 | ||
| Package size | mm | 3.0x12/4.5x25/5.5x35 | ||
|
Item
|
Single Mode
|
Multi Mode
|
||
|
Insertion loss
|
≤0.3dB
|
|||
|
Return loss
|
UPC≥50dB, APC≥60dB
|
≥35dB
|
||
|
Repeatability
|
0.1dB
|
|||
|
Working Times
|
≥1000 times
|
|||
|
Operating Temperature
|
-40℃ to +85℃
|
|||
|
Optical Cable Diameter
|
Ф0.9mm,Ф2.0mm,Ф3.0mm
|
|||
|
3D Specification
|
||||
|
Item
|
UPC Polishing
|
APC Polishing
|
||
|
Ferrule Diameter (mm)
|
2.5 / 1.25
|
2.5 / 1.25
|
||
|
Radius of Curv (mm)
|
10~25 / 7~25
|
5~12
|
||
|
Fiber Height (nm)
|
-125~50
|
±100
|
||
|
Apwex Offset (um)
|
≤50
|
≤50
|
||
