Cat5e Ethernet Cable 24awg Bare Copper Unshielded UTP PVC Jacket

100 rolls
MOQ
Negotiable
Price
Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket
Features Gallery Product Description Request A Quote
Features
Specifications
Origin: Sichuan,china
Product Name: F/UTP With Shielding Layer BC Line 24awg Standard Ethernet Cat5e Lan Cable
Model: F/UTP Category 5 Cable
Brand: Aitong
Minimum Order Quantity: 1000 Pieces
Packing Details: 305 M / Winding Box
Delivery Time: 7-15 Working Days
Term Of Payment: Letter Of Credit, Telegraphic Transfer
Supply Capacity: 50000 M / Day
Color: Blue
High Light:

Cat5e Ethernet Bulk Cable

,

F/UTP Ethernet Bulk Cable

,

Unshielded CAT5e Lan Cable

Basic Infomation
Place of Origin: China
Brand Name: Aitong
Certification: ISO9001
Model Number: cat-5e-F/UTP
Payment & Shipping Terms
Packaging Details: 42cm*42cm*22cm
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 winding box day
Product Description

24awg Cat5e Ethernet Bulk Cable Pure Bare Copper Unshielded (F/UTP) PVC

Cat5e cable is a "twisted pair" network cable used for 1000Base-T Ethernet applications at speed of up to 350MHz of bandwidth. This cable is preferred for more advanced networking installations where a higher bandwidth than normal is required.

Cable Type
Category 5e
Shielding Type
F/UTP
Cable Jacket
PVC CM
Cable Length
1000ft (305m)
Reference Bandwidth
350MHz
Data Rate Support
10/100/1000Base-T
Wire Gauge
26AWG
Cable Color
Blue
Conductor Type
Stranded Pure Bare Copper
Insulation Diameter
0.85 ± 0.05
Conductor Diameter (mm)
0.480 ± 0.005
Cable Outer Diameter (mm)
5.3 ± 0.4
Maximum Installation Tension (N)
70
Bend Radius (mm)
22.8
Operating Temperature
-20 to +75°C (-4 to 167°F)
Installation Temperature
-10 to +50°C (-14 to 122°F)
Standard
ISO/IEC 11801, ANSI/TIA-568.2-D
Warranty
1 year



Construction

Connectix Cat

  • Application structured cabling, CCTV system, Telecom project etc.
  • Exceeds TIA/EIA-568B.2,ISO/IEC 11801 ,
  • Pass Fluke Test 100M. 100Mbps/1000Mbps,100Base-T,1000Base-T standard.
  • Can be used for voice, integrated service data network (ISDN).
  • Long transmission distance, small transmission loss, wear resistance, resistance to pressure.





Network Connectivity

Network Connectivity for Cabling Solutions

Blank patch panels worked with Cat5e shielded bulk cable, provide multiple access options for the backbone wiring of the data center MDA-HDA, and help eliminate cross-talk and prevent EMI.

Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket



▌Parameter



onstruction Indoor generic cabling (FTP) category 305m CCA line 24awg standard Ethernet Cat5e Lan cable
Operating temperature (T-T) -20˚C to +70˚C
Conforms to IEEE 802.3: 10Base-T, 100Base-T, 1000 Base-T standards; ANSI/TIA 568C; ISO/IEC 11801; RoHS2002/95/EC
Fire Rating Cca,s1.d0,a1
Inner Conductor 24 AWG plain copper
Insulation High density polyethylene
Colour Code Pair 1: White/Blue-Blue/White Pair 2: White/Orange-Orange/White Pair 3: White/Green-Green/White Pair 4: White/Brown-Brown/White
Jacket FR-LSZH
Overall Diameter 5.4 +/- 0.4 mm
Min. Bending Radius Installation 44mm
Min. Bending Radius Installed 22mm
DC Resistance < 9.4 Ω/100 m
Velocity Ratio 69%
Installation temperature (T-T) 0˚C to +50˚C



Mechanical Properties



Bending radius Installation 8 x D
Installed 4 x D
Temperature range During operation -40°C to + 85°C
During installation -15°C to + 50°C
Fire load 4 pair 515 MJ/km
Maximum tensile load During operation No load
During installation 130 N



Electrical Properties at 20°C



DC loop resistance   £ 158 Ω/km
Resistance unbalance   £ 2%
Insulation resistance (500 V) ³ 5000 MΩxkm
Capacitance at 800 Hz Nom. 43 nF/km
Capacitance unbalance (pair to ground) £ 1500 pF/km
Mean Characteristic impedance @ 100 MHz) 100 ± 5 Ω
Nominal velocity of propagation   0,75c
Propagation delay   £ 450 ns/100 m
Delay skew   £ 15 ns/100 m
Transfer impedance at 1 MHz £ 10 mΩ /m
at 10 MHz £ 8 mΩ /m
at 30 MHz £ 10 mΩ /m
Coupling attenuation   ³ 85 dB
Segregation classification Acc. to EN 50174-2 “D”





Nominal Transmission characteristics at 20°C



F



(MHz)

Attenuation



(dB/100m)

NEXT



(dB)

ACR



(dB/100m)

Return loss



(dB)

PS-NEXT



(dB)

PS-ACR



(dB/100m)

ELFEXT



(dB/100m)

PS-ELFEXT



(dB/100m)

1 2,1 90 88   87 85 85 82
4 4,0 90 86 27 87 83 85 82
10 6,3 90 84 30 87 81 79 76
16 8,0 90 82 30 87 79 75 72
20 9,0 90 81 30 87 78 73 70
31.25 11,4 90 79 30 87 76 69 66
62.50 16,5 86 70 30 83 67 63 60
100 21,3 83 62 30 80 59 59 56
155.00 24,2 81 57 26 78 54 57 54
200.00 31,5 78 47 25 75 44 53 50
250.00 35,8 77 41 25 74 38 51 48
300.00 47,1 73 26 23 70 23 47 44
600.00 60,1 71 11 20 68 8 44 41





▌Product mix


Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket


Panking



 Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket  Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cable weight Gross weight
9.3kg 10kg
Box size (CM) Specifications
21.5×35×35 305m/box



Application scenario



Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket
Network TV Desktop computer Notebook computer Printer
Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket Cat5e Ethernet Cable 24awg  Bare Copper Unshielded UTP PVC Jacket
Router Set top box Cabinet Camera



Frequently asked question (FAQ)

Q: Are you a cable and wire manufacturer?
— Yes, we are a professional wire and cable manufacturer.

Q: Can you offer a discount on cables?
— The price is negotiable according to the specification and quantity.

Q: Can you offer FREE samples?
— Yes,FREE samples are available, you just take care of the freight fee.

Q: What about your MOQ?
— Usually, our MOQ is 5000 Meters, but we’ d love to talk about your MOQ.

Q: Do you accept customize cables?
— Yes, we are more than happy to make OEM and ODM for you.

Q: How long is the lead time?
— Usually it’s about 10-14 days.
